Remote Commands Reference
R&S
®
RTC1000
178User Manual 1335.7352.02 ─ 02
Parameters:
<Roll> ON | OFF
*RST: OFF
ACQuire:FILTer:FREQuency <FilterFrequency>
Sets the limit frequency if CHANnel<m>:ARIThmetics is set to FILTer.
Parameters:
<FilterFrequency> Limit frequency with 3 dB attenuation.
Default unit: Hz
ACQuire:POINts:ARATe?
Retrieves the sample rate of the ADC, that is the number of points that are sampled by
the ADC in one second.
Return values:
<AcquisitionRate> ADC sample rate in Hz.
Usage: Query only
ACQuire:SRATe?
Returns the sample rate, that is the number of recorded waveform samples per sec-
ond.
Return values:
<SampleRate> Waveform samples per second (Sa/s)
Usage: Query only
ACQuire:STATe <Aquisition State>
Sets or queries the acquisition state of the instrument.
Acquisition and Setup
