Remote Commands Reference
R&S
®
RTC1000
289User Manual 1335.7352.02 ─ 02
BUS<b>:I2C:FRAMe<n>:BYTE<o>:STARt?
Returns the start time of the specified data byte.
Suffix:
<b>
.
1, 2
Selects the bus.
<n> Selects the frame.
<o> Selects the byte number.
Return values:
<StartTime> Range: depends on sample rate, and time base
Default unit: s
Usage: Query only
BUS<b>:I2C:FRAMe<n>:BYTE<o>:ACKStart?
Returns the start time of the acknowledge bit of the specified byte.
Suffix:
<b>
.
1, 2
Selects the bus.
<n> Selects the frame.
<o> Selects the byte number.
Return values:
<AckStartTime> Range: depends on sample rate, and time base
Default unit: s
Usage: Query only
BUS<b>:I2C:FRAMe<n>:BYTE<o>:ACCess?
Returns the acknowledge bit value of the specified data byte.
Suffix:
<b>
.
1, 2
Selects the bus.
<n> Selects the frame.
<o> Selects the byte number.
Protocol Analysis
