TRIGger:A:WIDTh:DELTa <Delta>
Defines a range around the width value specified using TRIGger:A:WIDTh:WIDTh.
Parameters:
<Delta> ±Δt ("Variation" softkey)
Range: Depends on the defined pulse width
(TRIG:A:WIDTH:WITDH)
*RST: 3.2E-9
13.4.4 Video/TV Trigger
TRIGger:A:TV:STANdard................................................................................................204
TRIGger:A:TV:POLarity.................................................................................................. 204
TRIGger:A:TV:FIELd...................................................................................................... 204
TRIGger:A:TV:LINE........................................................................................................205
TRIGger:A:TV:STANdard <Standard>
Selects the color television standard.
Parameters:
<Standard> PAL | NTSC | SECam | PALM | I576 | P720 | P1080 | I1080
*RST: PAL
TRIGger:A:TV:POLarity <Polarity>
Sets the polarity of the sync pulses. The edges of the sync pulses are used for trigger-
ing.
Parameters:
<Polarity> POSitive | NEGative
POSitive
If the video modulation is positive, the sync pulses are negative.
NEGative
If the modulation is negative, sync pulses are positive.
*RST: NEGative
TRIGger:A:TV:FIELd <Field>
Sets the trigger on the beginning of the video signal fields, or on the beginning of video
signal lines.
