R&S RTC1000 - Bus<B>:I2 C:frame<N>:Byte<O>:Value; Bus<B>:I2 C:frame<N>:Data

Remote Commands Reference
R&S
®
RTC1000
288User Manual 1335.7352.02 ─ 02
Suffix:
<b>
.
1, 2
Selects the bus.
<n> Selects the frame.
Return values:
<ByteCountInFrame> Number of words (bytes)
Example:
BUS:I2C:FRAM2:BCO?
-> 4
Usage: Query only
BUS<b>:I2C:FRAMe<n>:DATA?
Returns the data words of the specified frame.
Suffix:
<b>
.
1, 2
Selects the bus.
<n> Selects the frame.
Return values:
<DataWordsInFrame>Comma-separated list of decimal values of the data bytes.
Example:
BUS:I2C:FRAM2:DATA?
returns four data bytes:
-> 69,158,174,161
Usage: Query only
BUS<b>:I2C:FRAMe<n>:BYTE<o>:VALue?
Returns the decimal value of the specified byte.
Suffix:
<b>
.
1, 2
Selects the bus.
<n> Selects the frame.
<o> Selects the byte number.
Return values:
<ByteValue> Decimal value
Range: 0 to 255
Increment: 1
Example:
BUS:I2C:FRAM2:BYTE2:VAL?
-> 158
Usage: Query only
Protocol Analysis
