R&S RTC1000 - Refcurve<M>:Data:xincrement; Refcurve<M>:Data:xorigin; Refcurve<M>:Data:yincrement

Remote Commands Reference
R&S
®
RTC1000
236User Manual 1335.7352.02 ─ 02
Table 13-3: Header data
Position Meaning Example
1 XStart in s -9.477E-008 = - 94,77 ns
2 XStop in s 9.477E-008 = 94,77 ns
3 Record length of the waveform in samples 200000
4 Number of values per sample interval, usually 1. 1
Suffix:
<m>
.
1..4
Selects the reference waveform, the internal reference storage.
Parameters:
<Header> Comma-separated value list
Example: -9.477E-008,9.477E-008,200000,1
Usage: Query only
REFCurve<m>:DATA:XINCrement?
Returns the time difference between two adjacent samples of the indicated waveform.
The commands are relevant for data conversion if binary data format is defined (FORM
UINT, 8 | 16).
Suffix:
<m>
.
1..4
Selects the reference waveform, the internal reference storage.
Return values:
<Xincrement> Time in s
Usage: Query only
REFCurve<m>:DATA:XORigin?
Returns the time of the first sample of the indicated waveform. The commands are rel-
evant for data conversion if binary data format is defined (FORM UINT, 8 | 16).
Suffix:
<m>
.
1..4
Selects the reference waveform, the internal reference storage.
Return values:
<Xorigin> Time in s
Usage: Query only
REFCurve<m>:DATA:YINCrement?
Returns the voltage value per bit of the indicated waveform. The commands are rele-
vant for data conversion, if binary data format is defined (FORM UINT, 8 | 16).
Quickmath and Reference Waveforms
