Return values:
<Yorigin> Voltage in V.
Usage: Query only
CHANnel<m>:DATA:ENVelope:YRESolution?
Return the vertical bit resolution of the indicated waveform. The command is relevant
for data conversion, if binary data format is defined (FORM UINT,8|16|32).
Suffix:
<m>
.
Selects the input channel (1, 2).
Return values:
<Yresolution> For default waveforms, the resolution is 8 bit.
If high resolution, average or filter are set, the resolution is
16 bit.
Usage: Query only
13.3.6 Waveform Data Export to File
EXPort:WAVeform:SOURce............................................................................................191
EXPort:WAVeform:NAME............................................................................................... 191
EXPort:WAVeform:SAVE................................................................................................192
EXPort:WAVeform:SOURce <WaveformSource>
Defines the waveform to be exported.
Parameters:
<WaveformSource> CH1 | CH2 | D0...7 | QMA | RE1..4
CH1 | CH2
Analog channels CH1 | CH2.
D0...7
Pod, digital channels D0 to D7 are exported together
QMA
Quick Mathematics waveform
RE1..4
Reference waveforms RE1 | RE2 | RE3 | RE4.
EXPort:WAVeform:NAME <FileName>
Defines the path and file name for a waveform data file that will be saved with
EXPort:WAVeform:SAVE. Depending on which USB port the flash drive is connected
to, you either choose “/USB_FRONT” or “/USB_REAR” to specify the correct location.
Additionally, the format type via FORM {ASC, REAL, UINT, CSV} and the number of
points to export via CHANnel<m>:DATA:POINts should be defined.
Existing files will be overwritten.
