Remote Commands Reference
R&S
®
RTC1000
222User Manual 1335.7352.02 ─ 02
CURSor<m>:XRATio[:VALue]?
Returns the ratio of the x-values (e.g. a duty cycle) between the first and second cur-
sors and the first and third cursors: (x2-x1)/(x3-x1).
Set the unit of the result with CURsor<m>:XRATio:UNIT.
Return values:
<Ratio> Numeric value corresponding to the specified unit.
Usage: Query only
CURSor<m>:YRATio:UNIT <Unit>
Sets the unit for Y Ratio measurements with CURSor<m>:YRATio[:VALue]?.
Parameters:
<Unit> RATio | PCT
RATio
floating value
PCT
percent
*RST: RAT
CURSor<m>:YRATio[:VALue]?
Provides three cursors and measures the ratio of the y-values (e.g. overshooting)
between the first and second cursors and the first and third cursors: (y2-y1)/(y3-y1).
Set the unit of the result with CURSor<m>:YRATio:UNIT.
Return values:
<Ratio> Numeric value corresponding to the specified unit.
Usage: Query only
13.6.2 Quick View
MEASurement<m>:AOFF............................................................................................... 222
MEASurement<m>:AON.................................................................................................223
MEASurement<m>:ARESult?..........................................................................................223
MEASurement<m>:AOFF
Stops the quick measurement.
Suffix:
<m>
.
1 (the suffix is irrelevant)
Usage: Event
Measurements
