Parameters:
<DataPattern> String with max. 32 bit. Characters 0, 1, and X are allowed.
Example:
TRIG:A:SPI:PATT "0011XXXX0110"
Sets a 12-bit pattern.
TRIGger:A:SPI:PLENgth <PatternLength>
Defines how many bits build up the serial pattern.
Parameters:
<PatternLength> Range: 1 to 32
Increment: 1
*RST: 4
Example:
TRIG:A:SPI:PATT "0011XXXX0110"
TRIG:A:SPI:PLEN?
12
TRIG:A:SPI:PLEN 4
TRIG:A:SPI:PATT?
"0011"
TRIGger:A:SPI:POFFset <PatternBitOffset>
Sets the number of bits before the first bit of the pattern.
Parameters:
<PatternBitOffset> Number of ignored bits.
Range: 0 to 4095
Increment: 1
*RST: 0
13.16.3.3 Decode
BUS<b>:SPI:FCOunt?....................................................................................................273
BUS<b>:SPI:FRAME<n>:STATus?..................................................................................274
BUS<b>:SPI:FRAME<n>:STARt?....................................................................................274
BUS<b>:SPI:FRAME<n>:STOP?.....................................................................................274
BUS<b>:SPI:FRAME<n>:DATA?.....................................................................................275
BUS<b>:SPI:FRAME<n>:WCOunt?.................................................................................275
BUS<b>:SPI:FRAME<n>:WORD<o>:STARt?................................................................... 275
BUS<b>:SPI:FRAME<n>:WORD<o>:STOP?....................................................................276
BUS<b>:SPI:FRAME<n>:WORD<o>:MISO?.................................................................... 276
BUS<b>:SPI:FRAME<n>:WORD<o>:MOSI?.................................................................... 276
BUS<b>:SPI:FCOunt?
Returns the number of frames.
