Remote Commands Reference
R&S
®
RTC1000
283User Manual 1335.7352.02 ─ 02
13.16.5.3 Decode
BUS<b>:I2C:FCOunt?.................................................................................................... 283
BUS<b>:I2C:FRAMe<n>:STATus?.................................................................................. 283
BUS<b>:I2C:FRAMe<n>:STARt?.................................................................................... 284
BUS<b>:I2C:FRAMe<n>:STOP?..................................................................................... 284
BUS<b>:I2C:FRAMe<n>:ACCess?.................................................................................. 284
BUS<b>:I2C:FRAMe<n>:AMODe?.................................................................................. 285
BUS<b>:I2C:FRAMe<n>:AACCess?................................................................................285
BUS<b>:I2C:FRAMe<n>:ADDRess?................................................................................286
BUS<b>:I2C:FRAMe<n>:ADEVice?.................................................................................286
BUS<b>:I2C:FRAMe<n>:ASTart?....................................................................................286
BUS<b>:I2C:FRAMe<n>:ADBStart?................................................................................ 287
BUS<b>:I2C:FRAMe<n>:ACOMplete?............................................................................. 287
BUS<b>:I2C:FRAMe<n>:BCOunt?.................................................................................. 287
BUS<b>:I2C:FRAMe<n>:DATA?..................................................................................... 288
BUS<b>:I2C:FRAMe<n>:BYTE<o>:VALue?..................................................................... 288
BUS<b>:I2C:FRAMe<n>:BYTE<o>:STARt?..................................................................... 289
BUS<b>:I2C:FRAMe<n>:BYTE<o>:ACKStart?................................................................. 289
BUS<b>:I2C:FRAMe<n>:BYTE<o>:ACCess?................................................................... 289
BUS<b>:I2C:FRAMe<n>:BYTE<o>:COMPlete?................................................................ 290
BUS<b>:I2C:FCOunt?
Returns the number of received frames.
Suffix:
<b>
.
1, 2
Selects the bus.
Return values:
<FrameCount> Total number of decoded frames.
Usage: Query only
BUS<b>:I2C:FRAMe<n>:STATus?
Returns the overall state of the frame.
Suffix:
<b>
.
1, 2
Selects the bus.
<n> Selects the frame.
Protocol Analysis
