R&S RTC1000 - Mask:count; Mask:data; Mask:data:header; Mask:vcount

Remote Commands Reference
R&S
®
RTC1000
245User Manual 1335.7352.02 ─ 02
Parameters:
<Xaddition> The value is added to the positive x-values and subtracted from
the negative x-values of the mask limits in relation to the mask
center.
Range: 0 to 10
*RST: 0
Default unit: div
MASK:COUNt?
Returns the number of tested acquisitions.
Return values:
<TotalCount> Total number of tested acquisitions
Usage: Query only
MASK:VCOunt?
Returns the number of acquistions that hit the mask.
Return values:
<ViolationCount> Acquisition count
Usage: Query only
MASK:DATA?
Returns the data of the mask.
Return values:
<Data> List of values
Usage: Query only
MASK:DATA:HEADer?
Returns information on the mask waveform.
Table 13-4: Header data
Position Meaning Example
1 XStart in s 0.000E+00
2 XStop in s 5.990E+02
3 Number of samples 600
4 Number of values per sample interval. For masks
the value is 2.
2
Return values:
<DataHeader> Comma-separated value list
Masks
