R&S RTC1000 - Bus<B>:Spi:frame<N>:Start; Bus<B>:Spi:frame<N>:Status; Bus<B>:Spi:frame<N>:Stop

Remote Commands Reference
R&S
®
RTC1000
274User Manual 1335.7352.02 ─ 02
Suffix:
<b>
.
1, 2
Selects the bus.
Return values:
<FrameCount> Total number of decoded frames.
Usage: Query only
BUS<b>:SPI:FRAME<n>:STATus?
Returns the status of frames.
Suffix:
<b>
.
1, 2
Selects the bus.
<n> Selects the frame.
Return values:
<Status> OK | INCFirst | INCLast | INSufficient
OK
Frame is o.k.
INCFirst
First frame is incomplete
INCLast
Last frame is incomplete
INSufficient
Frame is insufficient
Usage: Query only
BUS<b>:SPI:FRAME<n>:STARt?
Returns the start time of the specified frame.
Suffix:
<b>
.
1, 2
Selects the bus.
<n> Selects the frame.
Return values:
<StartTime> Range: depends on sample rate and time base
Default unit: s
Usage: Query only
BUS<b>:SPI:FRAME<n>:STOP?
Returns the end time of the specified frame.
Protocol Analysis
