R&S RTC1000 User Manual

Remote Commands Reference
R&S
®
RTC1000
298User Manual 1335.7352.02 ─ 02
13.16.7.2 Trigger
TRIGger:A:CAN:TYPE....................................................................................................298
TRIGger:A:CAN:FTYPe.................................................................................................. 298
TRIGger:A:CAN:ITYPe................................................................................................... 299
TRIGger:A:CAN:ICONdition............................................................................................ 299
TRIGger:A:CAN:IDENtifier.............................................................................................. 300
TRIGger:A:CAN:DCONdition...........................................................................................300
TRIGger:A:CAN:DATA................................................................................................... 300
TRIGger:A:CAN:DLENgth............................................................................................... 300
TRIGger:A:CAN:ACKerror...............................................................................................301
TRIGger:A:CAN:CRCerror.............................................................................................. 301
TRIGger:A:CAN:FORMerror............................................................................................301
TRIGger:A:CAN:BITSterror............................................................................................. 301
TRIGger:A:CAN:TYPE <TriggerType>
Specifies the trigger mode for CAN.
Parameters:
<TriggerType> STOFrame | EOFrame | ID | IDDT | FTYPe | ERRCondition
STOFrame
Sets the trigger to the start of a frame.
EOFrame
Sets the trigger to the end of a frame.
ID
Sets the trigger to the ID of a frame.
IDDT
Sets the trigger to the ID and data of a frame.
FTYPe
Sets the trigger to the frame type.
ERRCondition
Sets the trigger to the error condition of a frame.
*RST:
STOF
TRIGger:A:CAN:FTYPe <FrameType>
Specifies the frame type for CAN.
Protocol Analysis
