TRIGger:A:CAN:IDENtifier <Identifier>
Specifies the identifier, depending of TRIGger:A:CAN:ITYPe setting only string with
11 or 29 characters is possible.
Parameters:
<Identifier> String containing binary pattern with max. 29 bit. Characters 0,
1, and X are allowed.
TRIGger:A:CAN:DCONdition <DataCondition>
Specifies the condition for the data.
Parameters:
<DataCondition> EQUal | NEQual | GTHan | LTHan
EQUal
Sets the condition for identifier to equal.
NEQual
Sets the condition for identifier to not equal.
GTHan
Sets the condition for identifier to greater than.
LTHan
Sets the condition for identifier to less than.
*RST: EQU
TRIGger:A:CAN:DATA <Data>
Specifies the data for CAN trigger. Depending of TRIGger:A:CAN:DLENgth setting
the number of characters is fixed, all bytes need to be complete.
Parameters:
<Data> String containing binary pattern with max. 64 bit. Characters 0,
1, and X are allowed. Make sure to enter complete bytes.
Example:
TRIG:A:CAN:DATA "10010110"
TRIGger:A:CAN:DLENgth <DataLength>
Specifies the data length for the CAN trigger.
Parameters:
<DataLength> Range: 0 to 8
Increment: 1
*RST: 1
Default unit: Byte
Protocol Analysis
