Remote Commands Reference
R&S
®
RTC1000
297User Manual 1335.7352.02 ─ 02
Parameters:
<Source> CH1 | CH2 | D0 .... D7
*RST: CH1
BUS<b>:CAN:TYPE <SignalType>
Sets the signal type of the CAN.
Suffix:
<b>
.
1, 2
Selects the bus.
Parameters:
<SignalType> CANH | CANL
CANH
CAN High
CANL
CAN Low
*RST: CANH
BUS<b>:CAN:SAMPlepoint <SamplePoint>
Sets the sample point for the CAN Decoder within the bit period.
Suffix:
<b>
.
1, 2
Selects the bus.
Parameters:
<SamplePoint> Range: 25 to 90
Increment: 1
*RST: 50
Default unit: %
BUS<b>:CAN:BITRate <BitRate>
Sets the user defined bit rate for the CAN Decoder.
Suffix:
<b>
.
1, 2
Selects the bus.
Parameters:
<BitRate> Range: 1.00E+02 to 1.0081E+06
*RST: 5.0000E+04
Default unit: Bit/s
Protocol Analysis
