R&S RTC1000 User Manual

Remote Commands Reference
R&S
®
RTC1000
199User Manual 1335.7352.02 ─ 02
TRIGger:A:MODE <TriggerMode>
Sets the trigger mode. The trigger mode determines the behaviour of the instrument if
no trigger occurs.
Parameters:
<TriggerMode> AUTO | NORMal
AUTO
The instrument triggers repeatedly after a time interval if the trig-
ger conditions are not fulfilled. If a real trigger occurs, it takes
precedence.
NORMal
The instrument acquires a waveform only if a trigger occurs.
*RST: AUTO
TRIGger:A:LEVel<n>[:VALue]
<Level>
Sets the trigger treshold voltage for edge and width trigger.
Suffix:
<n>
.
Selects the trigger input. 1, 2 selects the corresponding channel,
5 selects the external trigger input.
Parameters:
<Level> Trigger level in V.
Range: Depends on vertical scale.
TRIGger:A:SOURce <Source>
Sets the trigger source.
Parameters:
<Source> CH1 | CH2 | D0...D7 | EXTernanalog | LINE | PATTern | NONE
CH1 | CH2:
Analog channels
D0...D7:
Digital channels
EXTernanalog:
External TRIG IN connector on the front panel
LINE:
AC line for the edge trigger
PATTern:
Pattern
NONE:
No trigger source selected
*RST:
CH1
Trigger
