Parameters:
<Overload> ON | OFF
Use OFF to reset the overload status bit.
*RST: OFF
Example:
CHANnel2:OVERload?
Queries the overload status of channel 2.
CHANnel2:OVERload OFF
Resets the overload status bit.
CHANnel<m>:SKEW <Skew>
Skew or deskew compensates delay differences between channels caused by the dif-
ferent length of cables, probes, and other sources. Correct deskew values are impor-
tant for accurate triggering.
Suffix:
<m>
.
Selects the input channel (1, 2).
Parameters:
<Skew> Deskew value in s.
CHANnel<m>:THReshold <Threshold>
Threshold value for digitization of analog signals. If the signal value is higher than the
threshold, the signal state is high (1 or true for the boolean logic). Otherwise, the signal
state is considered low (0 or false) if the signal value is below the threshold.
Suffix:
<m>
.
Selects the input channel (1, 2).
Parameters:
<Threshold> Default values are:
TTL: 1.4 V
ECL: -1.3 V
CMOS: 2.5 V
*RST: 5.00E-01
CHANnel<m>:THReshold:FINDlevel
Sets the appropriate threshold level automatically.
Suffix:
<m>
.
Selects the input channel (1, 2).
Usage: Event
CHANnel<m>:THReshold:HYSTeresis <ThresholdHyst>
Defines the size of the hysteresis to avoid the change of signal states due to noise.
Acquisition and Setup
