Remote Commands Reference
R&S
®
RTC1000
251User Manual 1335.7352.02 ─ 02
Parameters:
<Function> SQUarewave | COUNter | ARBitrary | SPI | I2C | UART | CAN |
LIN | MANual
SQUarewave
Square wave function (e.g. for manual probe compensation).
COUNter
Definition of a 4 bit wide counter pattern.
ARBitrary
Definition of a 4 bit wide and 2048 samples deep pattern.
SPI
SPI BUS signals for measurements without measurement
object. Data rate 100 kBit/s, 250 kBit/s or 1 MBit/s.
I2C
I
2
C BUS signals for measurements without measurement object.
Data rate 100 kBit/s, 400 kBit/s, 1 MBit/s or 3.4 MBit/s.
UART
UART BUS signals for measurements without measurement
object. Data rate 9600 Bit/s, 115.2 kBit/s and 1 MBit/s.
CAN
CAN BUS signals for measurements without measurement
object up to 50 MBit/s.
LIN
LIN BUS signals for measurements without measurement object
up to 50 MBit/s.
MANual
Manual pattern mode.
PGENerator:PATTern:STATe <State>
Activates or deactivates the pattern.
Parameters:
<State> ON | OFF
*RST: OFF
PGENerator:PATTern:STIMe <SampleTime>
Defines the sample time of the pattern generator function.
Parameters:
<SampleTime> Range: 2.000E-08 to 4.200E+01
*RST: 2.000E-08
Default unit: s
PGENerator:PATTern:PERiod <PatternPeriod>
Defines the period of the pattern generator function.
Pattern Generator
