R&S RTC1000 User Manual

Remote Commands Reference
R&S
®
RTC1000
268User Manual 1335.7352.02 ─ 02
Suffix:
<b>
.
1, 2
Selects the bus.
<m> Selects the bit line
Parameters:
<Source> D0 .... D7
*RST: D0
Example:
BUS:CPAR:WIDT 4
BUS:CPAR:DATA0:SOUR D2
BUS:CPAR:DATA1:SOUR D3
BUS:CPAR:DATA2:SOUR D4
BUS:CPAR:DATA3:SOUR D5
BUS<b>:CPARallel:CLOCk:SOURce
<ClockSource>
Selects the digital channel that is used as clock line.
Suffix:
<b>
.
1, 2
Selects the bus.
Parameters:
<ClockSource> D0...D7
*RST: D7
BUS<b>:CPARallel:CLOCK:SLOPe <ClockSlope>
Selects if the data is sampled on the rising or falling slope of the clock, or on both
edges (EITHer). The clock slope marks the begin of a new bit.
Suffix:
<b>
.
1, 2
Selects the bus.
Parameters:
<ClockSlope> POSitive | NEGative | EITHer
BUS<b>:CPARallel:CS:SOURce <ChipSelectSource>
Selects the digital channel that is used as chip select line.
Suffix:
<b>
.
1, 2
Selects the parallel bus.
Parameters:
<ChipSelectSource> D0...D7
*RST: D6
Protocol Analysis
