7-6 Designing the Control Cabinet Rexroth EcoDrive Cs Drives
DOK-ECODR3-DKC**.3-CS*-PR02-EN-P
7.4 Wire Routing in the Control Cabinet
• Maintain a distance of at least 100 mm between power cables and
control or signal cables (e.g. feedback cables) or
• separate cable duct with metal divider
Metal cable duct
MB5008F1.FH7
2...4 mm
>100 mm
Plastic cable duct
Fig. 7-5: Cable duct variants
Note: For details please see Project Planning Manual
"Electromagnetic Compatibility (EMC) in Drive and Control
Systems", document typecode
DOK-GENERL-EMV********-PRxx.
7.5 EMC in the Control Cabinet
Note: For details please see Project Planning Manual
"Electromagnetic Compatibility (EMC) in Drive and Control
Systems", document typecode
DOK-GENERL-EMV********-PRxx.
