Rexroth EcoDrive Cs Drives Additional Components 10-37
DOK-ECODR3-DKC**.3-CS*-PR02-EN-P
Type Code
1. Object
1.1 Transformer . . . . = TRAFO
2. Product
2.1 DST. . . . . . . . . . . . . . . . . . . . . . . = DST
3. Nominal power
3.1 2.0 kVA . . . . . . . . . . . . . . . . . . . . . . . . . . . = 2,00
3.2 2.5 kVA . . . . . . . . . . . . . . . . . . . . . . . . . . . = 2,50
3.3 4.0 kVA . . . . . . . . . . . . . . . . . . . . . . . . . . . = 4,00
3.4 5.0 kVA . . . . . . . . . . . . . . . . . . . . . . . . . . . = 5,00
3.5 7.5 kVA . . . . . . . . . . . . . . . . . . . . . . . . . . . = 7,50
3.6 10.0 kVA . . . . . . . . . . . . . . . . . . . . . . . . . . . = 10,00
3.7 12.5 kVA . . . . . . . . . . . . . . . . . . . . . . . . . . . = 12,50
3.8 15.0 kVA . . . . . . . . . . . . . . . . . . . . . . . . . . . = 15,00
3.9 18.0 kVA . . . . . . . . . . . . . . . . . . . . . . . . . . . = 18,00
3.10 20.0 kVA . . . . . . . . . . . . . . . . . . . . . . . . . . . = 20,00
3.11 25.0 kVA (for vertical mounting only) . . . . . = 25,00
3.12 35.0 kVA (for vertical mounting only) . . . . . = 35,00
3.13 50.0 kVA (for vertical mounting only) . . . . . = 50,00
4. Construction (Design)
4.1 suitable for mounting into IP55 housing . . . . . . . . . . . . . . . = G
4.2 horizontal mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = L
4.3 vertical mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = S
5. Nominal input voltage (Phase-Phase)
5.1 e.g., AC 380 V, AC 415 V, AC 440 V . . . . . . . . . . . . . . . . . . . . . = 380, 415, 440
6. Nominal output voltage (Phase-Phase)
6.1 e.g., AC 230 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = 220
7. Special design
7.1 Does not apply to standard transformers.
7.2 Frequency: e.g., 100 Hz . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = 100HZ
7.3 max. line diameter: e.g., 10 mm
2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
= 10MM
7.4 Protecting style: e.g., IP23, in protecting housing ST0 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = IP23
7.5 Nema-type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = NEMA
7.6 UL standard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = UL-N
8. Standard reference
Standard Title Edition
DIN EN 60529 Degrees of protection provided by enclosures (IP code) 2000-09
(IEC 60529:1989 + A1:1999); German version
EN 60529:1991 + A1:2000
Note:
 = Field does not apply
1234 6789
1
05 1234 6789
2
05 1234 6789
3
05 1234 6789
4
05
Example:
Abbrev.
Column
TRAFO DST 4 , 00 / L / 380 , 415 , 440- 220 10MM
Fig. 10-55:Type code
