Rexroth EcoDrive Cs Drives Identifying the Components 9-3
DOK-ECODR3-DKC**.3-CS*-PR02-EN-P
Type Plate at the Motor
typenschild_motor.fh7
Fig. 9-4: Type plate at the motor
typenschild_motor_text_en.fh7
Company name
Example K40/02 means week 40 in year 2002
Production week
Part number
Producing Country
Motor type
Barcode
Hardwareindex
A15
SN295553-F1234
Continued Number
Identification of supplier
Serial Number
Part number
Prefix
Fig. 9-5: Motor type plate
