REXROTH EcoDrive Cs - Encoder Emulation Cable RKG0008

Rexroth EcoDrive Cs Drives Additional Components 10-5
DOK-ECODR3-DKC**.3-CS*-PR02-EN-P
Encoder Emulation Cable RKG0008
white
brown
green
gray
black
pink
blue
red
1
2
3
4
5
6
7
8
drive controller
UA1+
UA1-
GND
GND
UA2+/CLK+
UA2-/CLK-
UA0+/Data+
UA0-/Data-
order length = length of unfinished cable
RKG0008RKG0008
100
70
0,14 mm
2
0,14 mm
2
0,14 mm
2
0,14 mm
2
0,14 mm
2
0,14 mm
2
0,14 mm
2
0,14 mm
2
Fig. 10-5: Encoder emulation cable
