REXROTH EcoDrive Cs - Control Voltage Connection

Rexroth EcoDrive Cs Drives Technical Data (Drive Controllers) 4-15
DOK-ECODR3-DKC**.3-CS*-PR02-EN-P
Control Voltage Connection
(data at 25 °C ambient temperature)
Designation Symbol Unit DKC**.3
control voltage U
N3
V AC200-240 +10%, -15%
frequency f Hz 50/60
max. allowed undervoltage U
N3max
V AC 264 ( = 240V +10%)
max. inrush current I
EIN3
A 37.5 at AC 264 V ( = 240 V +10%)
max. input capacitance C
N3
mF 0.039
power consumption (at X1 at U
N
=200 V) P
N3
W SERCOS Drive: 8.6
basic device: 7.2
basic device + SERCOS: 8.8
basic device + DeviceNet: 8.6
basic device + PROFIBUS: 10.2
power consumption (at X1 at U
N
=240 V) P
N3
W SERCOS Drive: 9.0
basic device: 7.6
basic device + SERCOS: 9.1
basic device + DeviceNet: 9.0
basic device + PROFIBUS: 10.6
Fig. 4-15: Control voltage connection
