1.4 Type Codes
Note: The following figures illustrate the basic structure of the type
codes. Your sales representative will help you with the current
status of available versions.
Drive Controllers with Analog/Parallel Interface
1. Product
1.1 DKC . . . . . . . . . . = DKC
2. Line
2.1 1 . . . . . . . . . . . . . . . . . . . = 01
3. Design
3.1 3 . . . . . . . . . . . . . . . . . . . . . . . . = 3
4. Rated current
4.1 4 A . . . . . . . . . . . . . . . . . . . . . . . . . . = 004
4.2 8 A . . . . . . . . . . . . . . . . . . . . . . . . . . = 008
4.3 12 A . . . . . . . . . . . . . . . . . . . . . . . . . . = 012
4.4 18 A . . . . . . . . . . . . . . . . . . . . . . . . . . = 018
5. DC-bus nominal voltage
5.1 DC 300 V . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = 3
6. Firmware
6.1 Multi interface general purpose . . . . . . . . . . . . . . . . = MGP
7. Firmware version
7.1 e.g., 01 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = 01
8. Nature of the firmware
8.1 Standard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = V
9. Firmware release status (update) (00 to 99)
9.1 Release status (the currently valid status
= status of the items list delivered) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = RS
Illustration example: DKC01.3-XXX-3
1234 6789
1
05 1234 6789
2
05 1234 6789
3
0512346789
4
05
Example:
Abbrev.
Column
DKC01.3-004-3-MGP-01VRS
Fig. 1-4: Type code for drive controllers with analog/parallel interface
