Rexroth EcoDrive Cs Drives Electrical Connections 5-45
DOK-ECODR3-DKC**.3-CS*-PR02-EN-P
5.3 Mounting a Master Communication Module
CAUTION
Possible damage to the master communication
module due to ESD!
⇒ Put on an earthing clip.
Removing the Shipping Brace
fkm_transportsicherung.fh7
FWA-ECODR
3-MGP-01VRS-MS
Made in Japan
123456
K40/02
123456-F0001
SN123456-F0001
A15
X6
9
8
7
6
5
4
3
2
1
9
8
7
6
5
4
3
2
1
ADDRESS
NODE
0
0
Rexroth
ECODRIVE
Cs
S1
H1
S2
S3
LINE ERROR
X1
X2
X3
1. Unscrew two screws of the shipping brace at the drive controller.
2. Remove the shipping brace.
