REXROTH EcoDrive Cs - Motor MSM030

Rexroth EcoDrive Cs Drives Motors 8-3
DOK-ECODR3-DKC**.3-CS*-PR02-EN-P
Motor MSM030
1234 6789
1
05 1234 6789
2
05 1234 6789
3
05 1234 6789
4
05
Example:
Abbrev.
Column
MSM030B- 0300 -NN-C0-CG1
1. Product
1.1 MSM. . . . . . . . . = MSM
2. Size
2.1 030 . . . . . . . . . . . . . . . . . = 030
3. Length
3.1 Lengths . . . . . . . . . . . . . . . . . = B, C
4. Windings
4.1 MSM030B . . . . . . . . . . . . . . . . . . . . . = 0300
4.2 MSM030C . . . . . . . . . . . . . . . . . . . . . = 0300
5. Cooling mode
5.1 natural convection, without blower . . . . . . . . . . . . = NN
6. Encoder
6.1 Incremental encoder. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .= C0
6.2 Multiturn absolute encoder. . . . . . . . . . . . . . . . . . . . . . . . . = M0
7. Electrical connection
7.1 cable tail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = C
8. Shaft
8.1 key per DIN 6885-1.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = C
8.2 plain shaft . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = G
9. Holding brake
9.1 without holding brake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = 0
9.2 electrical release 1.27 Nm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = 1
10. Standard reference
Standard Title Edition
DIN 6885-1 Drive Type with Fastenings without Taper Action; 1968-08
Parallel Keys, Keyways, Deep Pattern
Fig. 8-2: Type code for motor MSM030
