REXROTH EcoDrive Cs - X2, Additional Choke and Braking Resistor

5-6 Electrical Connections Rexroth EcoDrive Cs Drives
DOK-ECODR3-DKC**.3-CS*-PR02-EN-P
X2, Additional Choke and Braking Resistor
Technical Data of the Terminal Connector
schnittstellen_X2.fh7
TX
RX
S20
2
1
ON
X4
X5
X6
9
8
7
6
5
4
3
2
1
9
8
7
6
5
4
3
2
1
ADDRESS
NODE
00
Rexroth
ECODRIVE
Cs
S1
H1
S2
S3
LINE ERROR
X20
X21
X4
X5_3 X5_2 X5_1
INPUTíF200V-240V
X3 X2 X1
X6
DL1
DL2
RB1
RB3
RB2
Fig. 5-9: Terminal connector X2
Type Number of poles Type of design
spring tension 5 socket on connector
Fig. 5-10: Design
Cross section
single-core
[mm²]
Cross section
in AWG
gauge No.
0,75 - 2 18 - 14
Fig. 5-11: Connection cross section
Graphic Representation
Design
Connection Cross Section
