REXROTH EcoDrive Cs - Master Communication

1-8 Introduction to the System Rexroth EcoDrive Cs Drives
DOK-ECODR3-DKC**.3-CS*-PR02-EN-P
Master Communication
1. Product
1.1 ECM . . . . . . . . . = ECM
2. Line
2.1 1 . . . . . . . . . . . . . . . . . . . = 01
3. Design
3.1 1 . . . . . . . . . . . . . . . . . . . . . . . . . = 1
4. Interface
4.1 CANopen. . . . . . .. . . . . . . . . . . . . . . . = CN01
4.2 DeviceNet (open style). . . . . . . . . . . . . = DN01
4.3 DeviceNet (micro style) . . . . . . . . . . . . = DN02
4.4 none (cover) . . . . . . . . . . . . . . . . . . . . = NNNN
4.5 PROFIBUS-DB. . . . . . . . . . . . . . . . . . . . = PB01
5. Other design
5.1 none . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = NN
Illustration example: ECM01.1
1234 6789
1
05 1234 6789
2
05 1234 6789
3
05 1234 6789
4
05
Example:
Abbrev.
Column
ECM01 . 1- PB01 -NN
Fig. 1-7: Type code for master communication
