Rexroth EcoDrive Cs Drives Additional Components 10-23
DOK-ECODR3-DKC**.3-CS*-PR02-EN-P
10.3 Braking Resistor
Notes
Note: When an external braking resistor is used, the drive has to be
informed of this fact by means of the DriveTop commissioning
software (call in DriveTop by menu item "Drive Functions ->
Drive controller").
The internal braking resistor of the drive controller causes a derating of
the continuous DC bus power. By connecting an external braking resistor
a derating of the continuous DC bus power can be prevented.
With regard to the connection of the external braking resistor see
chapter 5.
Identification
1. Product
1.1 EBR . . . . . . . . . = EBR
2. Line
2.1 1 . . . . . . . . . . . . . . . . . . . = 01
3. Design
3.1 1 . . . . . . . . . . . . . . . . . . . . . . . . . = 1
4. Nominal power
4.1 e.g. 100 Watt. . . . . . .. . . . . . . . . . . . . = 0100
5. Resistor
5.1 e.g. 100 Ohm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = 100R
6. Construction
6.1 vertical (upright format or rather standing). . . . . . . . . . . . . . . . . .= V
6.2 horizontal (flat format or rather lying). . . . . . . . . . . . . . . . . . . . . .= H
7. Protection mode
7.1 e.g. IP50. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = D
1234 6789
1
05 1234 6789
2
05 1234 6789
3
05 1234 6789
4
05
Example:
Abbrev.
Column
E B R 0 1 . 1 - 0 1 0 0 - 1 0 0 R - V D
typenschl_ebr_en.EPS
Fig. 10-32: Type code
