REXROTH EcoDrive Cs - Ground Connection

Rexroth EcoDrive Cs Drives Electrical Connections 5-11
DOK-ECODR3-DKC**.3-CS*-PR02-EN-P
Ground Connection
Technical Data of the Terminal Connector
TX
RX
S20
2
1
ON
X4
X5
X6
9
8
7
6
5
4
3
2
1
9
8
7
6
5
4
3
2
1
ADDRESS
NODE
00
Rexroth
ECODRIVE
Cs
S1
H1
S2
S3
LINE ERROR
X20
X21
X4
X5_3 X5_2 X5_1
INPUTíF200V-240V
X3 X2 X1
X6
schnittstellen_erde.fh7
ground
Fig. 5-18: Ground connection
Type Number Type of design
terminal block 2 threaded terminal end for
M4 ring cable lugs
Fig. 5-19: Design
Cross section
single-core
[mm²]
Max. cross section
in AWG
gauge No.
2.0 14
Fig. 5-20: Connection cross section
Contrary to the safety instruction in chapter 3.5 a copper conductor cross
section of 2 mm
2
would be sufficient.
Maximum 1 m
Graphic Representation
Design
Connection Cross Section
Cable Length
