Rexroth EcoDrive Cs Drives Additional Components 10-25
DOK-ECODR3-DKC**.3-CS*-PR02-EN-P
Mounting
CAUTION
Danger of damages due to hot parts!
⇒
The surface of a braking resistor can reach
temperatures of approx. 230 °C. Pay attention to a
sufficient distance to neighboring devices and
components.
Mount the braking resistor vertically at the rear panel of the control
cabinet. The distance to neighboring devices and components must be at
least 40 mm.
Electrical Data
Item Value
resistance 100 Ohm
continuous bleeder power* 100 W
energy absorption 1000 Ws
Operating voltage between the
connection wires
max. 900VDC clocked
Insulation: internal structure according to UL 508 C
Sparking distance in air and creepage
distance from conductive housing of
resistor to metallic conductive
components (according to EN50178,
rating: 600V).
≥ 5.5 mm
Insulation resistance 20 MOhm
Insulation voltage AC2500V according to EN 50178
Connection wires:
Length 400 mm ±5 mm
Cross section 1,3 mm
2
(AWG 16)
Wire end sleeve CuZn - 3 claws resp. 3 notches
Stability of temperature 250 °C
UL-Listing ULstyle1659/VDE0295 CI.5) AWM
600V
* Conditions: convection cooling, no heat sink, surface
temperature = 250 °C, ambient temperature = 25 °C
Fig. 10-35: Electrical Data
