Rexroth EcoDrive Cs Drives Additional Components 10-13
DOK-ECODR3-DKC**.3-CS*-PR02-EN-P
SUP-E04-DKC*CS-ENCODR (Encoder Adapter)
"SUP-E04-DKC*CS-ENCODR" is a module for adapting 1Vss encoders to
the drive controller. The module must be plugged on interface X4 on the
drive controller.
Note: The "SUP-E04-DKC*CS-ENCODR" is not contained in scope
of supply.
Dimensions
70.5
64
201
geberadapter_abmessungen.fh7
246
77
Fig. 10-14: Drive controller with encoder adapter
