Rexroth EcoDrive Cs Drives Additional Components 10-19
DOK-ECODR3-DKC**.3-CS*-PR02-EN-P
SUP-E05-DKC*CS-SURGEP
The "SUP-E05-DKC*CS-SURGEP" contains accessories
(NTC thermistor; 33 Ohm at 25 °C and 19.6 Ohm at 40 °C) for reducing
the inrush current of the drive controller. The "SUP-E05-DKC*CS-
SURGEP" is suitable for 100 W, 200 W, and 400 W drive controllers.
CAUTION
Risk of damage by heat!
⇒
400 W drive controllers (DKCxx.x-012) that are
operated with SUP-E05-DKC*CS-SURGEP may
only be operated with a maximum power of 70%.
With higher load the NTC thermistor gets too hot.
Note: For 750 W drive controllers (DKCxx.x-018) the
SUP-E05-DKC*CS-SURGEP is not suitable.
Connect "SUP-E05-DKC*CS-SURGEP" to terminal X2 of the drive
controller (see mounting instructions in the leaflet enclosed).
Note: The "SUP-E05-DKC*CS-SURGEP" is not contained in scope
of supply.
