4-14 Technical Data (Drive Controllers) Rexroth EcoDrive Cs Drives
DOK-ECODR3-DKC**.3-CS*-PR02-EN-P
Note: 750 W devices (DKCxx.3-0018) are designed for three-phase
operation! Single phase operation reduces the service life of
the drive controllers significant.
ecocs_derating_750.FH7
0,7
0,8
1
200 170
264
power supply voltage in V
load factor
Fig. 4-14: Derating with single-phase operation (750 W devices)
With 100, 200, and 400 W devices single-phase operation doesn't cause
derating.
Single-Phase Operation
