REXROTH EcoDrive Cs - Page 207

Rexroth EcoDrive Cs Drives Additional Components 10-33
DOK-ECODR3-DKC**.3-CS*-PR02-EN-P
DST 2,5/S/380,415,440-220
Fig. 10-47: Dimensions
weight 16 kg
terminal 4 mm
2
Fig. 10-48: Data
