5-4 Electrical Connections Rexroth EcoDrive Cs Drives
DOK-ECODR3-DKC**.3-CS*-PR02-EN-P
Meaning Note
mains filter Is used for radio interference suppression
transformer When the mains voltage is higher than 240 V you must use a transformer (e.g.
autotransformer) to reduce the voltage
magnetic contactor Switches the supply voltage of the motor on or off.
From the input of the magnetic contactor the lines for the control voltage are branched off.
L1-conductor at L1C and N-conductor at L2C.
braking resistor By connecting an external braking resistor a derating of the continuous DC bus power can
be prevented.
Connection is realized at RB1 and RB2.
If you do not use any external braking resistor, the RB2 and RB3 connections must be
jumpered.
The braking resistor is available as an accessory.
voltage supply of holding
brake
If a motor with holding brake is used, the voltage supply of the holding brake must be
realized externally.
The holding brake is connected at the X5_3 interface (see page 5-18).
Data for the holding brake: see chapter "Holding Brake" on page 8-29
encoder cable If a motor with encoder is used, an encoder cable must be connected to the X4 interface.
The encoder cable is available as an accessory.
motor cable The motor cable contains:
the lines for connecting the motor (U, V, W, ground)
the line with ring cable lug for connecting the cable shield to the ground connection of
the drive controller
the separately shielded lines including connector for connecting the holding brake to
the X5_3 interface (BR+, BR-)
The motor cable is available as an accessory.
RS232 cable The RS232 cable is used to connect a PC to the drive controller.
The RS232 cable is available as an accessory.
master communication Depending on the design of the drive controller, one of the following master
communications can be used:
SERCOS
DeviceNet
PROFIBUS-DP
CANopen
Fig. 5-5: Notes on the schematic overall connection diagram
