1-4 Determing Drive and System Configurations SYNAX200
DOK-SYNAX*-SY*-07VRS**-PR01-EN-P
PPC Motion Control
The motion control PPC can be adapted to meet numerous application
requirements by using various option modules.
The motion control itself is mounted on a module carrier. Module carrier
can also be fitted with I/O modules.
PPCs not fitted with option modules are basic devices.
The following option modules are available:
• ARCNET-/PPC link assembly.
• Fieldbus modules.
This option module with designation DAQ serves for coupling of PPCs
and serves for communication with higher automation level (e.g., SPS) via
ARCNET interface.
Fieldbus slave interfaces are available for the fieldbusses Profibus (DPS),
Interbus (IBS) and DeviceNet (DNS).
Note: The SYNAX200 system is adapted to the hardware on the
machine in two steps:
• First the drive concept in terms of the motor is
determined. This includes drive amplifiers and linear
scale (as part of the basic drive configuration).
• Then PPC motion control function and plug-in card
assignment to the PPC motion controls is determined.
Basic devices
Option modules
ARCNET-/PPC link assembly
Fieldbus module
