7-18 Drive Configurations SYNAX200
DOK-SYNAX*-SY*-07VRS**-PR01-EN-P
Drive Configuration
The following equipment is needed for all three drives and is always
based on both precision and power requirements:
Axis Drive controller Motor
rotary die-cut HDS03.2-W075 MHD
anvil zylinder HDS03.2-W075 MHD
folding drive HDS04.2-W200 2AD
Fig. 7-18: Drive equipment
The result is the basic drive configuration HS12-01 on section 7.6. The
selection of the control-related plug-in modules follows the guidelines of
section 6.
A DFF card is needed for the master axis circuit.
The drive configuration follows the guidelines in section 7.
This results the following drive configuration for example:
Axis Configuration
rotary die-cut HS09 (with DFF01)
anvil cylinder HS12
folding drive HS12
Fig. 7-19: Drive configuration
For checking the reliability of the resulting drive configuration and for
determining the relevant configuration number, see the table on page 7-1
ff.
How to Order the Drive Controller
Pos. 1 drive controller HDS03.2-W074-HS09-..-FW
Pos. 1.1 relevant firmware FWA-DIAX04-ELS-05VRS-MS
Pos. 2 drive controller HDS03.2-W075-HS12-..-FW
Pos. 2.1 relevant firmware FWA-DIAX04-ELS-05VRS
Pos. 3 drive controller HDS04.2-W200-HS12-..-FW
Pos. 3.1 relevant firmware FWA-DIAX04-ELS-05VRS
