REXROTH SYNAX200 - Interface Module Terminal Diagrams

SYNAX200 Appendix 11-5
DOK-SYNAX*-SY*-07VRS**-PR01-EN-P
Profibus Interface DPS01
SY7PR105.FH7
PROFIBUS-DP
Slave module
X75 PROFIBUS interface
(slave)
X79 PROFIBUS diagnosis
interface RS232 C
(project planning interface)
1
6
DP-SLAVE
X79
X75
RDY
STA
RUN
ERR
1
6
Fig. 11-7:Profibus interface DPS01
