SYNAX200 PPC Motion Control Configuration 4-9
DOK-SYNAX*-SY*-07VRS**-PR01-EN-P
4.6 Specifications
General Information
Cable cross section of
Power supply feeder:
0.75 mm² to 1.5 mm²
Attachment in the control cabinet: with RMB02.2 module carrier on DIN rail TS 35 x 27 x 15
Protection rating: IP 20, EN 60529
Relative humidity: 5-85%, no condensation (operation)
5-95%, no condensation (transport)
Atmospheric pressure: 86-106 kPa
Operating temperature - environment: 0 to 45°C
Storage and transport temperature: -25°C to 70°C
Enclosure dimensions (B x H x T)
PPC-R01.1:
PPC-R02.1:
41,5 x 192 x 150
83.7 x 192 x 150
Weight: (PPC-R01/PPC-R02) 1.1kg / 1.3kg
Battery backup (only included if the optional
PPM memory module and the real-time clock
are used)
To be replaced every year
Battery type Order name: Battery Lithium 3.5 V, preassembled
Fig. 4-11: General specifications
Power supply
Supply / rated voltage: 24 V
DC
-15% +20% to EN61131-2: 1994
AC voltage component: 5% of the rated voltage
Absolute limits: 19.2 to 30 V
DC
, ripples included
Max. current consumption: (PPC-R01)
(PPC-R02)
0,7 A (+supply voltage for I/O modules up to 2.6 A)
1.2 A (+supply voltage for I/O modules up to 2.6 A)
Fig. 4-12: Power supply
Digital inputs and outputs
Digital inputs (X1) Current-sinking (to ground), floating
V
i,Low
= 0V...5V; V
i,High
= 15V...30V
Digital outputs (X1) Rated current 0.5 A, floating, V
OH,min
= U
ext
-3V
delay = 400µs max.
Watchdog relay NO contact V
n
=24 V, I
max
= 150mA
Fig. 4-13: Inputs and outputs
