4-10 PPC Motion Control Configuration SYNAX200
DOK-SYNAX*-SY*-07VRS**-PR01-EN-P
EMC
Emitted interference to EN 55022 Class A (industrial environment)
Noise immunity to EN 61000-4-2 (ESD) Rating criterion B
Noise immunity to EN 61000-4-4 (burst) Rating criterion B
Noise immunity to EN 61000-5-5 (surge) Rating criterion B
Fig. 4-14: EMC data
Interfaces
Programming interface (PROG) RS232/RS422/RS485 (D-SUB, 15-way female connector), isolated
General serial interface (COM) RS232/RS422/RS485 (D-SUB, 15-way female connector)
BT bus Indramat BT bus (D-SUB, 9-way female connector)
Fig. 4-15: Interface specifications
