SYNAX200 PPC Link 9-5
DOK-SYNAX*-SY*-07VRS**-PR01-EN-P
Commissioning
First the PPC link and the fibre-optics lengths are parametrized via
SynTop and the PPCs are brought into operating mode.
The active PPC link is displayed on displays H11 or H12 at each PPC
using the parametrized PPC link. (Precisely one link master and several
link slaves).
The H17 and H18 distortion displays must be checked and if necessary
the transmission power of the immediate physical predecessor must be
corrected or the fibre-optics lead checked for any damage.
In the case of a parametrized simple ring (no double ring) the H18
distortion displays will light up. This state is correct.
Clearing Errors
PPC link problems are signalled with binary PPC outputs and the
following diagnoses
Dis-
play
C-0-0048
Error
number
C-0-0047
Diagnostic text
C-0-0046
Diagnostic
information
F40 40 "PPC link - transmission path
defective"
10000h
F42 42 "PPC link - master position fault
(MDT)"
10000h
F43 43 "PPC link - master position fault
(AT)"
n = address
F44 44 "PPC link - link address set - not
permitted"
10000h
F93 93 "DAQ: SERCOS interface - ASIC:
intialization error"
10000h
F15 190 "PPC link - other link master already
active"
10000 h
Fig. 9-7: Error messages with PPC link errors
In such cases, the H11, H12, H17 and H18 displays can be used to locate
the cause.
Causes can be:
• incorrectly set transmission power of primary and secondary rings
• wrong parametrization of PPC link (simple ring, double ring, no PPC
link)
• defective fibre-optics cable.
