11-6 Appendix SYNAX200
DOK-SYNAX*-SY*-07VRS**-PR01-EN-P
INTERBUS Interface IBS03
SY7PR106.FH7
X65 INTERBUS interface (in coming)
(slave)
X66 INTERBUS interface (out going)
INTERBUS
module
IBS-SLAVE
X66
X65
RDY
RUN
TR
UL
RC
RD
BA
Fig. 11-8: INTERBUS interface IBS03
