4.10 Motion Control Configuration when Using the PPC-R
Configuration designation
DPS IBS DNS DAQ03 2nd serial
on slot plate
PPC-R01.2N-P1N-NN-FW
PPC-R01.2N-P1N-S1-FW
X
PPC-R01.2N-P1N-P2-FW
X
PPC-R01.2N-P1N-B4-FW
X
PPC-R01.2N-P1N-V2-FW
X
PPC-R01.2N-P1N-Q1-FW
X
PPC-R02.2N-P1N-NN-NN-NN-FW
PPC-R02.2N-P1N-NN-P2-NN-FW
X
PPC-R02.2N-P1N-Q1-P2-NN-FW
XX
PPC-R02.2N-P1N-B2-NN-NN-FW
X
PPC-R02.2N-P1N-Q1-B2-NN-FW
XX
PPC-R02.2N-P1N-V2-NN-NN-FW
X
PPC-R02.2N-P1N-Q1-V2-NN-FW
XX
PPC-R02.2N-P1N-Q1-NN-NN-FW
X
Fig. 4-21: Coonfiguration selection when using the PPC-R
DPS: PROFIBUS-DP Slave interface
IBS: INTERBUS-S Slave interface
DNS: DeviceNet Slave interface
DAQ: ARCNET Slave interface and PPC link interface card
2. ser:: Second serial interface on plug-in slot plate (only PPC-R01)
