REXROTH SYNAX200 - Appendix: Component Dimensional Sheets and Diagrams; Module Carrier Dimensions

SYNAX200 Appendix 11-1
DOK-SYNAX*-SY*-07VRS**-PR01-EN-P
11 Appendix
11.1 Dimensional Sheets, Terminal Diagrams RECO
Mounting Dimensions Module Carrier RMB02.2-02
9
12
4,5
2,25
98
42 42
217
120
47
77
Tophat rail
TS35 x27 x15
54.5
56
7
2
Screw for locking
the subrack on
the tophat rail
Fig. 11-1: Module carrier RMB02.2-02
