REXROTH SYNAX200 - General Safety Guidelines and Fibre-Optics Cable Handling

SYNAX200 Set-Up SYNAX200 Ring 8-5
DOK-SYNAX*-SY*-07VRS**-PR01-EN-P
General Safety Guidelines
DANGER
High-energy light
Risk of blindness and eye injury
⇒ Do not look into the light (transmitter output or fiber
optic cable end)
CAUTION
Error during mounting or when handling
fiber optic cable components could be mechanically
damaged
⇒ Do not screw fiber optic cable connector in too tightly
CAUTION
Error during mounting or when handling
fiber optic cable could be damaged
⇒ Mechanical limit values must be maintained
Handling
Connecting the Fibre-Optics Cables
Fibre-optics cables are connected as follows at the transmitter
TX (PPC-R)
X10 (DSS 2.1 in DIAX03 or DIAX04 and ECODRIVE)
X20 (ECODRIVE03).
Fibre-optics cables are connected as follows at the receiver
RX (PPC-R)
X11 (DSS 2.1 in DIAX03 or DIAX04 and ECODRIVE)
X21 (ECODRIVE03).
Storage
When storing the fibre-optics cables, please note that
• the protective caps must be in place
• the mechanical limit values are maintained
• the thermal limit values are maintained.
Connections transmitter side
Connections receiver side
