REXROTH SYNAX200 - Installation Dimensions of Module Carrier RMB02.2-02

SYNAX200 PPC Motion Control Configuration 4-3
DOK-SYNAX*-SY*-07VRS**-PR01-EN-P
ca. 235
ca. 300
56,5
2
247,55
40,55
54,5
1515
ca. 183
RMB
Mounting rail
TS 35 x 27 x 15
Bemaßung_Einbau.FH7
Fig. 4-3: Installation dimensions of PPC-R01.2 and PPC-R02.2
Installation dimensions of module carrier RMB02.2-02
9
12
4,5
2,25
98
42 42
217
120
47
77
Tophat rail
TS35 x27 x15
54.5
56
7
2
Screw for locking
the subrack on
the tophat rail
RMB02.2_Maß.FH7
Fig. 4-4: Module carrier RMB02.2-02
