REXROTH SYNAX200 - Page 129

SYNAX200 Appendix 11-9
DOK-SYNAX*-SY*-07VRS**-PR01-EN-P
Pin Assignments
Specifiactions:
- Low: -10V ... +8V
- High: +17 ... +30V
- Input current I
E
High < 10mA
- Power loss Pv ca. 4W
- Weight ca. 290g
1
2
3
4
5
6
7
8
9
10
R ME02.2-16-DC024
0V
L
0V
L
GND
R
E
-
+
+U
L
= 24VDC
I*.0.0
I*.0.1
I*.0.2
I*.0.3
I*.0.4
I*.0.5
I*.0.6
I*.0.7
I*.1.1
I*.1.2
I*.1.3
I*.1.4
I*.1.5
I*.1.6
I*.1.7
I*.1.0
RME02.2-16-DC024_Anschl.fh7
X1 X2
Fig. 11-11: Wiring diagram RME02.2-16-DC024
