SYNAX200 Appendix 11-11
DOK-SYNAX*-SY*-07VRS**-PR01-EN-P
Pin Assignments
1
2
3
4
5
6
7
8
9
R ME02.2-32-DC024
X1
0V
L
X2 X3 X4
Specifications:
- Low: -10V ... +8V
- High: +17 ... +30V
- Input current I
E
High < 10mA
- Power loss ca. 2,5W
- Weight ca. 300g
GND
R
E
+-
+U
L
= 24 VDC
I*.0.0
I*.0.1
I*.0.2
I*.0.3
I*.0.4
I*.0.5
I*.0.6
I*.0.7
I*.1.1
I*.1.2
I*.1.3
I*.1.4
I*.1.5
I*.1.6
I*.1.7
I*.1.0I*.2.0
I*.2.1
I*.2.2
I*.2.3
I*.2.4
I*.2.5
I*.2.6
I*.2.7
I*.3.1
I*.3.2
I*.3.3
I*.3.4
I*.3.5
I*.3.6
I*.3.7
I*.3.0
RME02.2-32-DC024_Anschl.FH7
Fig. 11-13: Wiring diagram RME02.2-32-DC024
