SYNAX200 Appendix 11-21
DOK-SYNAX*-SY*-07VRS**-PR01-EN-P
Pin Assignments
1
R MA02.2-16-RE230-200
+U od. L1
0V od. N
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
+U od. L1
0V od. N
Specifications:
- switching voltage: U
A
max = 230V
eff
- switching power: P
A
max = 50W ... 220W
(voltage-dependent)
- power loss: Pv ca. 4W
- weight ca. 440g
Q*.1.0
Q*.1.1
Q*.1.2
Q*.1.3
Q*.1.4
Q*.1.5
Q*.1.6
Q*.1.7
Q*.0.0
Q*.0.1
Q*.0.2
Q*.0.3
Q*.0.4
Q*.0.5
Q*.0.6
Q*.0.7
R MA02.2-16-RE230-200_Anschl.FH7
X1 X2
Fig. 11-23: Wiring diagram RMA02.2-16-RE230-200
